panel furniture
customized furniture
cabinets and wardrobes
office furniture
solid wood furniture
tables
chairs
doors and Windows
wood products
decoration industries
density board
ecological board
multi-layer board
particle board
straight solid wood board
aluminum honeycomb board
| item | value |
| Condition | New |
| Range of Spindle Speed(r.p.m) | 20000rpm - 24000rpm |
| Positioning Accuracy (mm) | 1mm |
| Number of Axes | 1 |
| No. of Spindles | Single |
| Working Table Size(mm) | 2100*3100 |
| Machine Type | CNC Router |
| Travel (X Axis)(mm) | 2100mm |
| Travel (Y Axis)(mm) | 3100mm |
| Repeatability (X/Y/Z) (mm) | 1mm |
| Spindle Motor Power(kW) | 9kw |
| CNC or Not | CNC |
| Place of Origin | China |
| Guangdong | |
| Brand Name | MINGD |
| Voltage | AC380V/50HZ |
| Dimension(L*W*H) | 4150*3100*2100mm |
| Power (kW) | 20 |
| Weight (KG) | 3500 |
| Warranty | 1 Year |
| Key Selling Points | Easy to Operate |
| Applicable Industries | Garment Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Construction works , Food & Beverage Shops, Advertising Company |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 1 Year |
| Core Components | Bearing, Motor, Pump, Gear, PLC, Engine, Gearbox |
| X-axis maximum positioning speed | 70m/min |
| Y-axis maximum positioning speed | 70m/min |
| Z-axis maximum positioning speed | 20m/min |
| Number of spindles | 12,auto knife changed |
| Knife handle diameter | 12.7, 6.35, 12, 10, 6 |
| Spindle speed | 24000r/min |
| Working air pressure | 0.6-0.8Mpa |
| X-axis machining range | 2100mm |
| Y-axis machining range | 3100mm |
| Z-axis machining range | 170mm |
Screen
Tsinghua Ziguang high-definition industrial screen, Taiwan Baoyuan system/new generation control interface design, user-friendly, foolproof operation, operators can take up the job after simple training, without the need for technical workers. The machine is agile and efficient, helping you achieve a leap in production capacity.
control unit
The important electrical components in the control cabinet are all imported electrical components such as Schneider; Main road Equipped with a filter, it can eliminate interference and ensure the stability of the control system.
servo motor
The servo drive adopts the Leisai 1500W high-power servo motor, which has the highest transmission performance of high speed and precision, and the maximum torque of the motor can reach 350%.
Pushing material for secondary vacuum cleaning
Pushing device with vacuum system, automatically cleaning the table surface With automatic grabbing function, automatic positioning。
Knife setting instrument
Pushing device with vacuum system, automatically cleaning the table surface With automatic grabbing function, automatic positioning.
